| Specification for JS-S1 Pet GPS Collar |
| |
Product type |
Smart Pet GPS Collar |
| Main features |
GPS+WIFI+LBS multi-mode precise positioning,voice intercome, intelligent dormancy,real time tracking |
| 1.Structure parts |
| Structure parts |
Type |
Specification |
Remarks |
| ID design |
fashion and luxury |
|
| Whole machine size |
120 LengthX35 WidthX12.5mm Thickness (Pet collar inner diameter:600mm) |
|
| Color |
white, black, red |
|
| Button |
1 button( Poweror off button) |
|
| Screen |
0.66 inch OLED |
|
| gps antenna |
High sensitive ceramics active antenna |
|
| Battery |
500mAh |
|
| SIM card |
1 pc |
|
| G-sensor |
supported |
|
| I/O port |
Magnetic suction charging |
|
| 2. Hardware parts |
| Hardware parts |
Chip |
MTK MT6261 |
|
| GPS chip |
MTK3337 |
|
| GPRS |
Class12 |
|
| GPS singal |
L1,1575.42MHz C/A code |
|
| GPS channels |
20 channels |
|
| GPS chip receive sensitivity |
Tracking sensitivity：-159dBm，capture sensitivity：-143dBm |
|
| GPS location accuracy |
5～15M |
|
| WIFI location accuracy |
5-30M |
|
| LBS location accuracy |
100-1000M |
|
| Minimum standby current |
less than 0.5 mA |
|
| Average standby current |
less than 2.5 mA |
|
| Average working current |
less than 55mA |
|
| Working temperature |
-20～70℃ |
|
| Working humidity |
5% to 95% non-congealable |
|
| Test and certification |
Can pass CAT, 3C and CE certification |
|
| GPS antenna |
Built-in high sensitivity ceramic antenna |
|
| GSM antenna |
Built-in four frequency PIFA antenna |
|
| Bluetooth |
BT 3.0 (Usually Off) |
|
| G-Sensor |
Supported |
|
| Speaker |
AAC 1609 speaker(The same supplier with Apple phone） |
|
| MIC |
Supported |
|
| 3. Software parts |
| Software parts |
Support operate system |
Support 2.3 and above system, IOS5.0 and above |
|
| Voice intercom |
Support voice intercome function |
|
| Call function |
Support voice monitor function |
|
| Language support |
Simplified Chinese, English |
Compatible with support for multi-languages |
| GSM+GPRS+GPS+WIFI |
GPS+WIFI+LBS multi-mode positioning |
|
| Support AGPS |
Cool start 26 seconds positioning |
|
| Power management |
Ultra-low consumption of power managment, intelligent dormancy |
|
| Smart Geo-fence |
Can automatic alarm when out of range |
|
| Historicial route |
Can check three months' historical route |
|
| Wireless upgrading |
Software remote upgrading, remote debugging maintence , remote setting parameters |
|
